BUILT-IN SCALING (AUTO FIT CONTENT TO WALL): YES
INPUTS: 5 - HDMI 1.3 (2x), SL-DVI (1x), 3G-SDI (1x), Opt 1
OUTPUTS: LED OUTPUTS - 6
GENLOCK: YES
IMAGE MOSAIC (MULT. PROCESSORS ON 1 WALL): YES
VIDEO LOOP: YES
MONITOR: HDMI
BUILT IN FIBER SLOTS: YES
WINDOWS/LAYERS: 3 (via PIP)
3D: YES (Supports 3D Effect. Output capacity is cut in half when 3D is enabled)
CONTROL:
ETHERNET ( Webpage Control via Network) / USB Type B (PC Control)
LOADING CAPACITY:
MAX PIXELS PER LED OUTPUT: 650,000 pixels
TOTAL PIXELS: 3.9million pixels
MAXIMUM INPUT RESOLUTION: 1920 x 1200 @ 60Hz (When using HDMI Input)
MAX OUTPUT WIDTH/HEIGHT: 10240 pixels x 8192 pixels (W x H or H x W)
